| Mechanical size | 204 x 143 x 50 mm Panel Mount | ||||
| Cut-out size | 189 x 128 mm | ||||
| Housing material | Powder-coated aluminum, Gray | ||||
| Input voltage | 18-32 VDC | ||||
| CPU | Dual Cortex-A9 1.0GHz 512kBL2cache | ||||
| RAM | 1 GB | ||||
| FLASH | 4 GB | ||||
Size diagonal |
7" diagonal | ||||
| Resolution | 800x480 pixels | ||||
| Number of serial ports | 1 Port 9pin DSUB | ||||
| Serial port 1 | - | ||||
| Serial port 2 | - | ||||
| Serial port 3 | - | ||||
| Serial port 4 | - | ||||
| Number of Ethernet ports | 2 | ||||
| Ethernet port 1 | 1x10/100 Base-T (shielded RJ45) | ||||
| Ethernet port 2 | 1x10/100 Base-T (shielded RJ45) | ||||
| Operating temperature | -10°C to +60°C | ||||
| Sealing front | IP65 | ||||
