| Mechanical size | 202 x 152 x 37 mm Panel Mount | ||||
| Cut-out size | 186 x 136 mm | ||||
| Housing material | Plastic (PC+ABS), Gray | ||||
| Input voltage | 18-32 VDC | ||||
| CPU | ARM Cortex A8 1000MHz | ||||
| RAM | 512 MB | ||||
| FLASH | 2 GB | ||||
Size diagonal |
7" diagonal | ||||
| Resolution | 800x480 pixels | ||||
| Number of serial ports | 2port9pinDsub, 1port3pinScrew | ||||
| Serial port 1 | RS 232 (RTS/CTS) | ||||
| Serial port 2 | RS422/485 | ||||
| Serial port 3 | RS 232 | ||||
| Serial port 4 | RS 485 | ||||
| Number of Ethernet ports | 2 | ||||
| Ethernet port 1 |
1x10/100
Base-T
(shielded RJ45) |
||||
| Ethernet port 2 | - | ||||
| Operating temperature | -10°C to +50°C | ||||
| Sealing front | IP65 | ||||
