| Display Type | 26,4 см / 10,4"-TFT | ||||
| Screen Resolution | 1024 x 768 Pixel(s) (XGA) | ||||
| Touch Technology |
projective-capacitive,
ten-touch control, analog resistive
(polyester) |
||||
| Brightness | 500 cd/qm | ||||
| Backlighting | LED | ||||
| Colors | 16.2 million colors | ||||
| Processor | Intel® Atom™ x7-E3950 2.0 GHz | ||||
| Cooling | passive | ||||
| Operating System | without operating system/ Windows® 10 IoT Enterprise LTSB 2019 (64-bit) |
||||
| RAM | 8 GB LPDDR4 | ||||
| Mass Storage | Flash eMMC, 64 GB (entegre)/ Flash eMMC, 64 GB + M.2 SSD, 128 GB | ||||
| Network | 2x Ethernet (10/100/1000 Mbps), RJ45 | ||||
| Interfaces | 1x COM (RS-232)/ 3x USB 3.0/ 1x USB 3.0 on the front with IP65 cover (can be deactivated via software) |
||||
| Optional Interfaces | 1x COM (RS-232) / LTE/GPS module / Wi-Fi 802.11a/b/g/n/ac + Bluetooth |
||||
| Audio | integrated speakers | ||||
| Housing Material | die-cast aluminum | ||||
| Mounting Type |
VESA MIS-D, 75
(integrated in back panel as a mounting option) |
||||
| Degree of Protection | IP66 | ||||
| Operation Temperature | -30 °C ... 60 °C | ||||
| Power Supply | 12 ... 48 V DC (9 .... 60 V DC IN) | ||||
| Dimensions | W 277 x H 249 x D 50 mm | ||||
